“Piccolo” Distal Radius Plates

PF Short Nail

PF Long Nail

Triangular plate

• Made of continuous carbon fibers reinforced polymer.
The Distal Radius plates are anatomically shaped.
• Standard & Narrow designs are available.
• Low profile: plate thickness 2.4mm.
• Screw holes accommodate both locking and non-locking screws.
• Polyaxial locking screws – up to 10° trajectory variation.
• Circumference radiopaque marking outlining plate contour for positioning & follow-up.
• CarboFix Distal Radius plates are FDA cleared*** and CE marked.

Features

• Radiolucent: Superior fracture imaging.
• Unparalleled fatigue strength.
• Improved modulus of elasticity.
• No cold welding.

Available sizes

Plate
Orientation
No. Shaft holes
Length
(mm)
Standard Distal Radius
Right / Left
3, 4, 7
52, 60, 90
Narrow Distal Radius
Right / Left
3, 4
52, 60
Triangular Distal Radius
Right / Left
3, 4
54, 63

• Head Locking Pegs: Ø2.0mm
• Head Locking & Non Locking Screws: Ø2.5mm
• Shaft Locking & Non Locking Screws: Ø3.5mm

* CarboFix nails & plates are supplied sterile

** CarboFix nails & plates are also known as Piccolo Composite® nails & plates
